ABF2-W  Wireless Outdoor Infrared Beam Sensor 2 Beams Infrared Detector Perimeter Alarms for Yards Perimeter Protection

ABF2-W Wireless Outdoor Infrared Beam Sensor 2 Beams Infrared Detector Perimeter Alarms for Yards Perimeter Protection

Lead Time :2–7 days

Product Attribute
ABF2-W
BONLOR
DC 3.6V
2 Beam
30-60m
ABS
Infrared LED
433mhz / EV1527
  • Product details
  • Certificate
  • Comments
  • Contact Supplier



Wireless Outdoor Infrared Beam Sensor 2 Beams Infrared Detector Perimeter Alarms For Yards Perimeter Protection

Integrated wireless design, eliminating the need for wiring, making installation simple and construction convenient.
Low-power design, with operating current as low as microampere levels, providing a long battery life and up to three years of
Equipped with 4-stage digital VF technology to prevent inter-beam interference during installation under challenging scenarios (ideal for long-range and stacked installations).
The product features dedicated mode indicator lights, enabling straightforward and precise optical corrections.
Incorporates secondary processing of IR signals (comparable to AGC functionality), guaranteeing a power reserve of over 90%, allowing for exceptional performance even in adverse weather conditions including wind, rain, frost & snow, snow, and direct sun exposure.
Supports low battery alerts and tamper detection alarms;
Robustly protected against water ingress: IP55
Range of wide-angle optical calibration: 360° (±180°) horizontally, and 90° vertically; the unique design with an inward extending brim offers strong resistance against sunlight interference

Specifications for Active Infrared Beam Sensor
Model
ABF2-30
ABF2-60
Detection Distance
30m
60m
Working voltage
3.6v
built-in battery
3.6V, 8500 mA
Working Current
transmitting current 170 uA; receiving current 180 uA
Application areas
Outdoor/Indoor
Communication range
≥100m (open space)
Detectio way
Infrared beam interruption alarm
Beam frequency
4 channel optional
Wireless frequency
433mhz / EV1527
Alarm cycle
≥25s
Alignment angle
360° (±180°) horizontally; 180° (±90°) vertically
Waterproof Grade
IP55
Operating temperature
-25°C~+55°C
Battery life
2 years
Case Material
PC
Dimensions
327*76*71mm
Packing & Delivery
Packing Details for Active Infrared Beam Sensor
PACKING
Neutral color box or customer's packing
PCS/CARTON
18PCS
GW/CARTON
18KG
CARTON SIZE
59*38*54 cm
